Akcie


Base definition

Types

  • Navigate to
  • Edit
  • Detail
  • Data repeater(pump)
  • Automatization
  • Other

Render

  • In header – ERPIO App is showing these actions in right menu
  • In row – ERPIO App is showing these actions after a click on row/item/appointment/ in view (if there is only one action, the action is immediately executed)
  • In context – not implemented in ERPIO App
  • Other – not implemented in ERPIO App

Additional

ShowActionIn

  • Auto – let E1 decide where to show action
  • Only popup – action is shown only in action popup after the click on the row
  • is hidden – action is not shown (used e.g. for navigation action for parameter input type cSet
  • Only detail – action is shown only in detail view

MetaData

Metadata e.g. for ScheduleView can be set up here.

Parametre

Extended config

Custom settings in the tab Extended (in the edit of a parameter)

For all input types

Tab

Add extended config as follows:

  • SysName: Tab
  • DType: String

Input name of the tab. Creates tab in the editor in the app.

By input type

cTextBox

IsRichText

Add extended config as follows:

  • SysName: IsRichText
  • DType: Boolean

Textbox on editor will be shown as Richt text editor.

cDecimal

MaskDef

Change decimal places with adding mask:

  • e.g. 3 decimal places use mask:
#,##0.000
  • e.g. 4 decimal places you can use mask:
f4

cSet

MultiSelectWithDelimiter

Add extended config as follows:

  • SysName: MultiSelectWithDelimiter
  • DType: String

Input delimiter character. Allows selecting multiple values in combo box in the editor. Value is returned as a list of selected values with chosen delimiter.

cCamera

IsGalleryVisible

Add extended config as follows:

  • SysName: IsGalleryVisible
  • DType: Boolean

Is set to true in the camera edit is also the picker from gallery shown.

cGallery

IsCameraVisible

Add extended config as follows:

  • SysName: IsCameraVisible
  • DType: Boolean

Is set to true in the picker from gallery the camera button is also shown.

Specific action types

Location On Map

Specific action used to open default navigation app

Action settings:

  • Type: Navigate to
  • Render: In row
  • Destination: Other
  • Show as: LocationOnMap

Parameters:

  • @BName – name of the object on map
  • @BData – coordinates or address

Open File

Specific action to use the open file functionality of the device.

Action settings:

  • Type: Navigate to
  • Render: In row
  • Destination: Other
  • Show as: OpenFile

Parameters:

  • @BName – file name
  • @BData – file binary

Share File

Specific action to use share functionality of the device.

Action settings:

  • Type: Navigate to
  • Render: In row
  • Destination: Other
  • Show as: ShareFile

Parameters:

  • @BName – file name
  • @BData – file binary

Open PDF

Specific action to open PDF in ERPIO App internal viewer.

Action settings:

  • Type: Navigate to/Edit (Edit – if you want to get back edited PDF and save it – then in Command should be INSERT/UPDATE)
  • Render: In row
  • Destination: Other
  • Show as: OpenPDF

Signature

Parameters:

  • @BName – file name
  • @BData – file binary

Print PDF

Specific action to printPDF with platform specific print manager (if available).

Action settings:

  • Type: Navigate to
  • Render: In row
  • Destination: Other
  • Show as: PrintPDF

Parameters:

  • @BName – file name
  • @BData – file binary

Floating action button
